product information:

   1.Product model: 10mm external IC magic light bar, 60 lights per meter, 20 segments/1 meter 30 lights, 10 segments

   2. Light source: SMD 5050 LED;

   3. Plate: FPCB, 10mm wide

   4. Chip: Taiwan Epistar chip, and other chips in Taiwan;

   5. Lamp bead model: external IC magic lamp beads;

   6. Gray scale: 256 levels, (1 meter 20/10 pixels);

   7. The number of LEDs: 30/60pcs/meter, every 3 lights is a group, which can be cut;

   8. Lighting angle: 180°;

   9. Lighting color: can be adjusted by the controller, white, red, yellow, blue, green, etc.;

  10. Standard working voltage: DC 12V;

  11. Power: 18W ±10% / m;

  12. Waterproof grade: not waterproof, dripping glue (IP65), casing (IP67), casing solid glue (IP68), etc.;

  13. Dimensions of FPCB board: Width: 10mm,

  14. FPCB color: white, black
